Midea MSV1-09HRFN1-MT0W User Manual

8
Code
2T0032500244
2T0032700154
Indoor code
220032503340
220032702340
Outdoor code
220037502530
220037701530
Inoor model
MSV1-12HRDN1-MQ0W
MSV1-18HRDN1-MQ0W
Outdoor model
MOC-12HDN1-MQ0W
MOF-18HDN1-MQ0W
Power supply
Ph-V-Hz
1Ph, 208-230V～, 60Hz
1Ph, 208-230V～, 60Hz
MINIMUM CIRCUIT AMPACITY
A
15
15
MAX.FUSE
A
20
20
Moisture Removal
L/h
1.2
1.8
Compressor
Model
DA108X1C-20FZ3
DA150S1C-20FZ
Type
ROTARY
Twin-rotary
Brand
GMCC
GMCC
Capacity
Btu/h
10918
15286
Input
W
855
1150
Rated current(RLA)
A
5.3
9.7
Locked rotor Amp(LRA)
A
10
----
Thermal protector
INT01L-4639 / CS-74
----
Thermal protector position
EXTERNAL
----
Capacitor
uF
35
35
Refrigerant oil/oil charge
ml
ESTER OIL VG74 / 480
ESTER OIL VG74/500
Indoor fan motor
Model
RPG20B
YDK36-4CB(A)
Brand
Welling
Welling
Input
W
43
79/58/50
RLA
A
0.2
0.39
LRA
A
0.23
0.48
Winding Resistance
Ω
381/267
242/79
Capacitor
uF
1.5
3
Speed(Hi/Mi/Lo)
r/min
1250/1060/900
1245 / 1040 / 940
Indoor unit
Dimension(W*D*H)
mm
845x165x286
1082x207x320
Dimension(W*D*H)
inch
33.27x6.50x11.26
42.60x8.15x12.60
Packing (W*D*H)
mm
905x285x355
1180x425x310
Packing (W*D*H)
inch
35.63x11.22x13.98
46.46x16.73x12.20
Net/Gross weight
Kg
10/13.5
14.5/20
Net/Gross weight
lbs.
22.05/29.76
31.97/44.09
Outdoor fan motor
Model
YDK24-6GB
YDK53-6FB
Brand
Welling
Welling
Input
W
72/53
166/105
RLA
A
0.33
0.74
LRA
A
0.41
0.95
Winding Resistance
Ω
293/169
56/76
Capacitor
uF
2.5
2.5
Speed
r/min
830/570
800/600
Outdoor unit
Dimension(W*D*H)
mm
760x285x590
845x320x700
Dimension(W*D*H)
inch
29.92x11.22x23.23
33.27x12.60x27.56

Midea MSV1-09HRFN1-MT0W Specifications

General

Brand	Midea
Model	MSV1-09HRFN1-MT0W
Category	Air Conditioner
Language	English
