MCAC-RTSM-2011-12 Midea Combo Type Heat Pump Water Heater Technical Manual
10
Safe class
IPX4
Rated current
A
0.3
Capacitor
μF
2.5
Evaporator coil
Number of rows
3
Tube pitch(a)x row
pitch(b)
mm
22×19.05
Fin spacing
mm
1.5
Fin type (code)
hydrophilic aluminum
Tube outside dia. and
type
mm
8
internal screw thread
Coil length x height
mm
482×352
Number of circuits
4
Water pipeline
Water inlet pipe
mm
DN20
Water outlet pipe
mm
DN20
Drainage pipe
mm
DN20
PT valve joint
mm
DN20
Heat exchanger
Dividing wall type heat exchanger
Solar heat exchanger
Water inlet pipe
mm
DN20
Water outlet pipe
mm
DN20
Heat exchanger
Stainless steel SUS316L
Dim.× Length
mm
22×10000
Max. pressure
MPa
0.7
E-heater
kW
3
Hot water yield
m³/h
0.086
Loading Quantity
20'/40'/40H
Pcs
21/47/47
Remark:
1. The test conditions: outdoor temp. 15/12℃(DB/WB), inlet water temp. 15℃, outlet water temp.45℃.
2. The specification may be changed for product improvement, please refer to the nameplate.
2. Operation range
E-heater running ambient temperature range: -30~45℃.
Heat pump running ambient temperature range: -7~43℃.
Water temperature limits:
Ambient temp. T4
Model
T4＜-7
-7≤T4＜-2
-2≤T4＜2
2≤T4＜7
7≤T4＜43
43≤T4
RSJ-15/190RDN3-D
Max temp
(Heat pump)
—
45
60
70
70
—
Max temp
(E-heater)
70
70
70
70
70
70
RSJ-35/300RDN3-D
Max temp
(Heat pump)
—
42
47
55
60
—
Max temp
(E-heater)
60
60
60
60
60
60
Note：Modes will be automatically selected by the unit. manually mode selection is unavailable
