MCAC-RTSM-2011-12 Midea Combo Type Heat Pump Water Heater Technical Manual
11
3. Performance diagram
3.1 The relationship between capacity and ambient temperature
Model: RSJ-15/190RDN3-D
Model: RSJ-35/300RDN3-D
1.00
1.50
2.00
2.50
3.00
3.50
4.00
4.50
5.00
-7 -2 2 7 10 15 20 25 30 35 40 43
(kw)
15--45 15--50 15--55 15--60
3.2 The relationship between COP and ambient temperature
Model: RSJ-15/190RDN3-D
Ambient temp()
