Midea RSJ-15/190RDN3-D

MCAC-RTSM-2011-12 Midea Combo Type Heat Pump Water Heater Technical Manual
20
No.
Part Name
No.
Part Name
1
Upper back cover
14.18
Inner enamel components
2
Filter
14.19
Tank cover ass'y
3
Ring
15
Front decorative boards
4
Barbed wire
16
Heater cover on
5
Barbed wire
17
Under the heater cover
6
Top cover
18
Temp.sensor ass'y
7
top front sheet
19
Temp.sensor ass'y
8
front volute
20
Temperature control waterproof cover
9
Display cover
21
Electronic expansion valve ass'y
10
Display panel
22
Pressure line cover
11
Motor
23
4-way valve ass'y
12
Centrifugal wind wheel assembly
24
Evaporator ass'y
13
back volute
25
Discharge temp sensor ass'y
14
Foam tank ass'y
26
Junction box cover
14.1
Temperature and pressure safety
valve
27
Room temp sensor ass'y
14.2
Water Outlet pipe
28
Junction box cover
14.3
Electric heating foam baffle
28.1
Wire joint, 3p
14.4
Thermometer
29
Compressor
14.5
Stator of temp. sensor
30
E-part box ass'y
14.6
Temp sensor
30.1
E-part box
14.7
Electric heating pipe water
30.2
Main control board ass'y
14.8
Water Inlet pipe
30.3
Transformer
14.9
Magnesium rod
30.4
Dual Relay
14.10
Supporting plastic tank block
30.5
Relay
14.11
Foam
30.6
Insert motor capacitor
14.12
Drain plug
30.7
Wire joint,2p
14.13
Tank bottom
30.8
Compressor capacitor
14.14
PT valve loop
30.9
Capacitor clamp
14.15
Tank shell
31
Electric control the lid
14.16
Water tank handle
32
Display board ass'y
14.17
Welded pipe temperature
