Midea RSJ-15/190RDN3-D

MCAC-RTSM-2011-12 Midea Combo Type Heat Pump Water Heater Technical Manual
22
No.
Part Name
No.
Part Name
1
The wind ring
16.7
Relay
2
Filter
17
Electronic Control Box Bracket
3
Net
18
Deck board
4
The front cover
19
On the heater cover
5
cover
20
Deck magnet
6
Magnesium rod plug
21
Magnet clip
7
Junction box cover
22
Magnet cover
8
Motor
23
4-way valve ass'y
9
Display panel
23.1
Pipe joint
10
Display board ass'y
23.2
Pressure controller
11
Centrifugal fan
23.3
4-way valve
12
Display cover
23.4
Solenoid
13
E-Part box cover
24
Electronic expansion valve ass'y
14
Tank foam components
24.1
EEV solenoid
14.1
Tank cover assembly
24.2
Solenoid valve winding
14.2
Froth plug
24.3
Electronic expansion valve
14.3
Temp sensor
24.4
Solenoid valve
14.4
Magnesium anode
25
Compressor
14.5
Thermometer
26
Discharge temp sensor ass'y
14.6
Stator of temp. sensor
27
Room temp sensor ass'y
14.7
Electric heating pipe water
28
Temp.sensor ass'y
14.8
seal ring of radiation pipe
29
Temperature sensor
14.9
Seal Stopper
32
Compressor electric heater
14.10
Drain plug assembly
33
Evaporator ass'y
14.11
Tank bottom cover
33.1
Evaporator
14.12
PT valve loop
33.2
Evaporator output pipe ass'y
14.13
Water tank handle
33.3
Evaporator input pipe ass'y
14.14
TP safety valve
35
Before scroll
15
Magnet frame
36
Compressor wire joint ass'y
16
E-part box ass'y
37
Screw plate
16.1
E-part box
39
Drain
16.2
Compressor capacitor
40
After the cover on
16.3
Main control board ass'y
41
Dry Filter
16.4
Transformer
42
Plumbing fixture
16.5
Motor capacitor
43
Electronic control box panels
16.6
Wire joint
