6.Internal view and dimension
6.1Main parts and their names
(The picture is only for reference, and specific appearance and configuration are subject to the real
product)
1. TEMP control box and knob
2. Freezer door
3. tray
4. Glass shelf
5. Glass shelf
6. Fruits and vegetables box
7. adjustable foot
8. hinge cover
9. steel wire guardrail
10. steel wire guardrail
11. steel wire guardrail
12.
13. steel wire guardrail
14.
6.2External dimension
Front view
Side view
