Midea UR-BC123CM-ST - 8. Dismantling of parts; 8.1 Parts on the door; 8.2 Parts inside the refrigerator

Service Manual, 2017-02
19 / 36
8. 8. Dismantling of parts
8.1 Parts on the door
Door seal
Door seal is installed into door liner groove.
1） Open the refrigerator door;
2） Take the door seal ①out of door liner;
Guardrail
1） Guardrail 1 、 2 、 3Grab the Guardrail and
squeeze it sideways
2） Pull out and remove from the refrigerator
1） Guardrail 4Push it along the direction indicated by
the arrowThen dismantle the guardrail
8.2 Parts inside the refrigerator
Shelves
