Midea UR-BC123CM-ST - 8.4 Air duct components refrigeratingchamber; 8.5 Air duct components in freezing chamber and fan motor; 8.6 Evaporator and temperature sensing system

Service Manual, 2017-02
21 / 36
There is a light switch on the side wall of the
refrigerating chamber.
1） Loosen the hook with small normal screwdriver
and pull out the switch until the wire connector
reveals.
Pilot light
None
Fresh light
None
8.4Air duct components refrigeratingchamber
Air duct components refrigeratingchamber
None
8.5Air duct components in freezing chamber and fan motor
Disassembly and installation of Air duct
None
Fan motor of air duct
None
8.6Evaporator and temperature sensing system
Evaporator in freezing chamber
/
Components on the evaporator
Defrost thermostat
None
Fuse
None
Defrost sensor
None
Defrost heater
None
Evaporator in refrigerating chamber
as shown in the picture, dismantle the temperature
induced tube from the evaporator, along the direction
shown by the arrow, squeeze the small door and
dismantle it along opposite direction;
Press the evaporator downwards along the direction 1,
then pull the evaporator horizontally along direction 2,
at last cut off the connected pipe of evaporator
Components on the evaporator
