1）
Lift up the division plate with a proper force and
pull it out towards yourself;
Drawer
The drawer is located at the bottom of freezing and
refrigerating chambers;
1） Pull the drawer out completely;
2） Lift it up slightly and take it out from the
refrigerator.
8.3 Light system
Light
 The light at the left of refrigerator chamber
1） Separation lamp cover from the temperature
control box
2） Remove the light bulb
Light switch
