20 | Midland G18 instruction guide
Technical specifications
General
Frequency range 446.00625- 446.09375 MHz (PMR446)
Channels 8 +91 pre-set
Working temperature -20°+55°
Operating voltage 7.4V
Operative Mode Simplex
Dimensions 113mm×56mm×38mm
(Antenna excluded)
Weight 240g (Battery included)
Impedance Antenna 50Ω
Duty cycle 5/5/90%
Transmitter
Frequency stability ±2.5PPM
Output power ≤500mW ERP
Max frequency deviation ≤2,5KHz
Audio distortion ≤3%
Adjacent channel power < 60 dB
Spurious radiation Within European legal terms
Occupied bandwidth Within European legal terms
Receiver
RF sensitivity <0.2UV@20 dB SINAD
Audio distortion ≤3%
Audio response 300Hz ÷ 3KHz
