25
ENGLISH
10 TECHNICAL SPECIFICATIONS
GENERAL
Channels - All international, USA, and Canada channels
Frequency generation - PLL synthesizer
Frequency range
MHz TX from 156.025 to 157.425 MHz
MHz RX from 156.300 to 162.000 MHz
Antenna Impedance Ohm 50
Power Supply VDC from 4.8 to 6 (4 AA rechargeable NiMH or alkaline batteries)
Operating Temperature Range °C from -15° to +55°
Size (H x L x W) mm 126 x 55 x 38
Weight g 157
TRANSMITTER
Output Power (@ 6 VDC)
W High Power 2
- Low Power 0.5
Modulation System - FM
Spurious reduction - According to ETSI regulations
RECEIVER
Sensitivity (@ 12dB SINAD) µV 0.35
Adjacent channel rejection dB 70
Audio Output (10% THD) mW 300
Intermediate frequencies
MHz First 21.7
KHz Second 455
CONNECTIONS
Socket for external microphone and charger - 2.5 mm stereo jack
Socket for external speaker - 3.5 mm mono jack
GPS RECEIVER MODULE
FASTRAX
Specifications are subject to modification without forewarning.
