Worktop cut-out calculation example for three appliances
A
Appliance width
less 8
B
Appliance
width
C
Appliance width
less 8
D
Worktop
cut-out
280 288 280 848
280 380 372 1032
280 576 568 1424
372 288 280 940
372 380 372 1124
372 576 568 1516
568 288 280 1136
568 380 372 1320
568 - 568 1136
All dimensions are given in mm
Installation of several appliances
35
