Technical data
59
Fan motor* 90 W
Cooktop lighting
DA 3660 2 x 3 W
DA 3690 3 x 4.5 W
Total rated load*
DA 3660 96 W
DA 3690 103.5 W
Voltage, frequency AC 230 V, 50 Hz
Fuse rating 10 A
Mains connection cable length 1.5 m
Weight
DA 3660 16 kg
DA 3690 19 kg
DA 3660 EXT 13 kg
DA 3690 EXT 16 kg
Extraction power* according to EN 61591, extraction ducting 125/150 mm
Setting 1 170/200 m³/h
Setting 2 260/300 m³/h
Setting 3 360/400 m³/h
Intensive setting 580/640 m³/h
Recirculation power**
Setting 1 150 m³/h
Setting 2 230 m³/h
Setting 3 320 m³/h
Intensive setting 550 m³/h
* For EXT models, the rated load and extraction power will depend on the type of external
mot
or fitted.
Length of connection cable to external motor: 1.9 m
