Installation under a countertop
a Steam oven
b Cabinet opening
c Terminal block
d Outlet or junction box
This should be accessible after the
appliance has been installed.
e Power cord
* Machine with glass front
** Machine with stainless steel
front
Appliance and cut out dimensions
49
(22 mm* /
23 mm**)
7/8"
(560 mm - 568 mm)
b
(600 mm)
d
( 500 mm)
0
3/8"
1/16"
11/16"
19
22
- 22
23
(460 mm - 465 mm)
- 18
1/8"
5/16"
18
5/8"
(455.5 mm)
(446 mm)
(549 mm)
(444 mm)
(85 mm)
a
c
e
(595 mm)
7/16"
23
1/2"
17
17
9/16"
1/4"
5/8"
21
3/8"
3
(83 mm)
3
15/16"
17
