The door hinges are set ex-works to
enable the doors to be opened wide.
However, if the opening angle of the
door needs to be limited for any reason,
the hinges can be adjusted to
accommodate this.
For example, if the appliance door hits
an adjacent wall when opened, the
opening angle can be limited to 90°.
^ Place the locking pins supplied for
limiting the door opening into the
hinges from above.
The door opening angle is now limited
to 90°.
Adjusting the door hinges
34
