Do not change the door hinging if
this appliance is to be installed
"side-by-side" with another
appliance. Each appliance must be
built-under into a separate niche
and the freezer must be installed on
the right-hand side of the
refrigerator.
Before building the appliance in, you
will need to decide on which side the
door is to be hinged. If left-hand door
hinging is required, follow the
instructions below.
To change the door hinging you will
need the following tools:
– a flat-bladed screwdriver,
– a selection of Torx
®
screwdrivers:
Torx
®
15, 20, 25.
Appliance door
^
Open the door.
^ Remove covers a, b and c with a
flat-bladed screwdriver.
^
Loosen fixing screws d slightly.
^
Slide the door outwards, lift it off e
and place it to one side.
^
Now remove fixing screws d and
screw them loosely into position at
the top e and the bottom f on the
opposite side
Use a power screwdriver to secure
the hinges - the screws are
self-tapping.
Changing the door hinging
35
