4. Adjusting the door front
When fitted the door front can be ad-
justed up to a maximum of 2 mm up-
wards or downwards to match adjoin-
ing base unit fronts.
Adjust the height of the door front
with the lower recessed adjusting
screw (Torx T20) at each side of the
machine door outer panel.
higher = turn clockwise.
lower = turn anti-clockwise.
5. Securing the door front
Secure the door front by tightening
the
upper recessed fixing screws
(Torx T20) at each side of the
machine door outer panel.
Plug the fixing screw recesses with
the plastic stoppers provided.
Installation
72
