There must be a distance of at
least 20 cm between the floor and
the bottom of the “Waterproof valve”
box, for either vertical or horizontal
installation.
If the stopcock is situated in the
worktop, a special angle connector
can be ordered from the Miele Spare
Parts Dept. (Part No. 2078910).
Lay the hose in such a way that it
does not rise above the bottom of
the “Waterproof valve” box (see illus-
tration).
Plumbing
80
