Miele G 7216 - Page 73

Cleaning and care
73
Removing the upper spray arm
2
1
 Push the upper spray arm upward
to engage the inner ratchet. Then un-
screw the spray arm by rotating the
screw thread counterclockwise
(view from below).
Removing the middle spray arm
2
1
 Rotate the screw thread of the middle
spray arm clockwise (view from
above) and remove the spray arm.
Removing the lower spray arm
 Remove the lower basket.
2
1
 Rotate the screw thread of the lower
spray arm counterclockwise (view
from above) and pull the spray arm
upward to remove.
