Technical Information
58
G 600/G 800
5.20 Middle Spray Arm Feed Pipe Removal
1. Remove the spray arm cover. See Section 5.19.
2. Remove the left side panel. See Section 5.3.
3. Remove the spring clip located at the top of the feed pipe near the flow-through
heater.
4. Lift upward on the feed pipe to remove.
Note:
When re-installing, ensure that the seal is installed on the feed pipe before
reinstallation.
5.21 Flow-Through Heater Removal
1. Remove the left side panel. See Section 5.3.
2. Fold up the insulation as needed.
3. Disconnect the heater electrical connections.
4. Disconnect the top and bottom hose connections.
5. Lift upwards on the heater assembly (Figure 5-19, Item 2) to release it from the
retainer.
Figure 5-19: Flow-Through Heater Assembly
Note:
When replacing a flow-through heater, the old seal (Figure 5-19, Item 1) should be
replaced as well.

Miele G 881 Novo Stella Specifications

General

Type	Freestanding
Control Panel	Electronic
Place settings	12
Energy efficiency class	A
Height	85 cm
Width	60 cm
Depth	60 cm
Color	White
