Cleaning and care
73
Door removal
The door weighs approx. 10kg.
The oven door is connected to the door
hinges by retainers.
Before removing the door from the
retainers, the locking clamps on both
door hinges have to be released.
 Open the door fully.
 Release the locking clamps by
turning them as far as they will go.
The oven could become damaged if
you incorrectly remove the door.
Never pull the door horizontally off its
retainers, as they will spring back
against the oven.
Never pull the door off the retainers
by the handle, as the handle could
break off.
 Raise the door up till it rests partially
open.
 Hold the door on either side and pull
it diagonally upwards off the
retainers. Make sure that the door
goes back on straight.

Miele H 7264 BP Specifications

General

Oven size	Large
Oven type	Electric
Cleaning type	Pyrolytic
Self-cleaning	Yes
Number of ovens	1
Reheat function	-
Total oven power	- W
Oven net capacity	76 L
Oven thermostat range	30 - 300 °C
Pizza making function	No
Number of shelf positions	5
Total oven(s) interior capacity	49 L
Door hinge	down
Cord length	1.7 m
Control type	Touch
Door material	Glass
Product color	Black, Stainless steel
Control position	Top front
Appliance placement	Built-in
Clock type	Electronic
Timer type	Digital
Lamp type	Halogen
Lamps quantity	1 lamp(s)
Current	16 A
Connected load	3600 W
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Energy efficiency index (EEI)	81.7
Energy consumption (conventional)	1.1 kWh
Energy consumption (forced convection)	0.71 kWh

Weight and Dimensions

Depth	568 mm
Width	595 mm
Height	596 mm
Weight	47000 g
Installation compartment depth	550 mm
Installation compartment width (min)	560 mm
Installation compartment height (min)	593 mm
