Fixing the spring clamps
Worktops made of wood
^ Position the spring clamps
(supplied) a in the positions shown
(see "Appliance dimensions and
worktop cut-out") so that they are
flush with the top edge of the cut-out,
and secure with the 3.5 x 25 mm
screws supplied.
Granite and marble worktops
^ Position the spring clamps a, and fix
in place using double-sided tape f.
^
Apply silicone g to the side edges
and lower edge of the spring clamps.
The screws are not required for granite
or marble worktops.
Installation
45
75
a
a
g
f
75
a
f
