Fixing the spring clamps
The exact positions of the spring
clamps are shown in the building-in
dimensions for the particular hob.
Worktops made of wood
^ Position the spring clamps (supplied)
a in the positions shown (see
"Building-in dimensions") by placing
them on the upper edge of the
cut-out as illustrated, and secure with
the 3.5 x 25 mm screws supplied.
Granite and marble worktops
^ Position the spring clamps a, and fix
in place using double-sided tape f.
^
Apply silicone g to the side edges
and lower edge of the spring clamps.
The screws are not required for
granite or marble worktops.
Installation
35
