Connecting the cooktop
37
Insert the plug casing on the cooktop
power cord into the plug connector
on the oven. Do not force the plug
casing into the connector.
The plug casing and plug connector
are designed so that only one
connection alignment is possible.
The protective ground wire is
integrated in the plug casing.
Connect the EMC ground, which
is attached to the bottom casing of
the cooktop (depending on the
model), to the cable lug on the oven.
