Miele PWM 514 Installations Plan

en - PWM514
35
Technical data
Voltage versions and electrical data
3NAC400V, 50/60Hz, EL A01Z
Supply voltage 3N AC 400V 50/60Hz
Frequency 50/60 Hz
Required fuse rating (on site) 16 A
Power rating 9,6 kW
Connection cable, min. cross-section 2,5 mm²
Cable gland
3NAC400V, 50/60Hz, RH
Supply voltage 3N AC 400V 50/60Hz
Frequency 50/60 Hz
Required fuse rating (on site) 16 A
Power rating 9,6 kW
Connection cable, min. cross-section 2,5 mm²
Cable gland
3NAC400V, 50/60Hz, EH
Supply voltage 3N AC 400V 50/60Hz
Frequency 50/60 Hz
Required fuse rating (on site) 16 A
Power rating 2,3 kW
Connection cable, min. cross-section 1,5 mm²
Cable gland
3AC230V, 50/60Hz, EL B04Z
Supply voltage 3 AC 230V 50/60Hz
Frequency 50/60 Hz
Required fuse rating (on site) 35 A
Power rating 9,6 kW
Connection cable, min. cross-section 4 mm²
Cable gland
Plumbing
Models with detergent drawer (DD)
Permitted flow pressure 1000 kPa
Maximum intake rate 47,5 l/min
Cold water connection
(to be provided on site, male thread according to DIN44991, flat seal)
3 x ½” with ¾” threaded union
Optional hard water connection, cold
(on-site external thread according to DIN44991, flat seal)
2 x ½” with ¾” threaded union (optional)
Hot water connection (≤70°C)
(on-site external thread according to DIN44991, flat seal)
1 x ½” with ¾” threaded union
Length of inlet hoses supplied 1,55 m
