Miele PWM 514 Installations Plan

en - PWM514
36
Drainage
Maximum drain water temperature 95 °C
Waste water connection (on machine) Plastic pipe HTDN 70
Drain (on site) ConnectionDN 70
Maximum drainage rate 200 l/min
Connection for equipotential bonding
Male thread M10
Toothed washers M10
Installation dimensions
Casing width (without add-on components) 795 mm
Casing height (without add-on components) 1331,5 mm
Casing depth (without add-on components) 897 mm
Overall machine width 799 mm
Overall machine height 1350 mm
Overall machine depth 995 mm
Minimum width of transport opening 900 mm
Minimum safety distance between wall and appliance front 1395 mm
Diameter of door opening 415 mm
Door opening angle 180°
Anchoring
Standard
Required anchor points 2
DIN571 wood screw (diameterxlength) 12 mm x 90 mm
Rawl plugs (diameterxlength) 16 mm x 80 mm
With plinth (UO/UG)
Required anchor points 4
DIN571 wood screw (diameterxlength) 12 mm x 90 mm
Rawl plugs (diameterxlength) 16 mm x 80 mm
Concrete plinth
Required anchor points 2
DIN571 wood screw (diameterxlength) 12 mm x 90 mm
Rawl plugs (diameterxlength) 16 mm x 80 mm
