Technical Information
30
S 2xx, S 3xx & S 4xx Canister Vacuums
to remove it.
3. Re-install the holder (Figure 5-4, Item 1) as follows:
a. Tighten screw (Figure 5-4, Item 2).
b. Lightly install screw (Figure 5-4, Item 5) so that the holder (Figure 5-4,
Item 1) can still be installed.
c. Insert the spring (Figure 5-4, Item 3) as shown in Figure 5-4 before
installing the holder. The longer spring arm (Figure 5-4, Item 4) must
point downwards.
d. Tighten screw (Figure 5-4, Item 5).
Figure 5-4: Dustbag Holder, S 27x
5.3.3 S 3xx
1. Open the dustbag compartment lid fully.
2. Unsnap and pull up the dustbag holder in the direction of the arrow.
3. Inserting a dustbag: With the dustbag folded, slide it into its holder. Close
the dustbag compartment lid.
Figure 5-5: Dustbag Holder, S 3xx
5.3.4 S 4xx
1. Remove the dustbag holder screws (Figure 5-1, Item 1) from the left and
right.
2. Remove the holder upwards.
