Technical Information
53
S
2xx, S 3xx & S 4xx Canister Vacuums
Figure 5-38: S 270i - S 276i, S 280i Suction Hose with Integrated Wiring
5.22.3 S 278i
Wired hose with slide potentiometer speed control and built-in socket in the
handle for the S 016 electric brush.
Figure 5-39: S 278i Suction Hose with Integrated Wiring
5.23 Turbo Brush (S 2xx Only)
Unscrew the screws (Figure 5-40, Item 2) to remove the cover (Figure 5-40,
Item 1). All brush parts are then accessible.
Note:
2-wire connection cable.
Note:
3-wire connection cable. Suction
power selector (slide
potentiometer) on the handle.
