Installation
*INSTALLATION*
35
Installation with a countertop extractor
Combination examples Numberxwidth [mm] Dimension
B
[mm]
Cooking
elements
Countertop
extractor
1x378 1x120 481
2x378 1x120 862
1x378
1x620
2x120 1226
3x378 2x120 1365
2x378
1x620
2x120 1607
4x378 2x120 1746
1x620 2x120 845
