Installation and connection
38
Rear view
a
Protruding lid for holding when
moving the tumble dryer (see
arrows)
b
Air inlet vent for cooling the
condenser unit
c
Mains connection cable
d
Hose for external drainage of
condensed water
e
Accessories for external drainage of
condensed water: hose clip, adapter
and hose holder
Installation site
Make sure the dryer door can be
opened without hindrance after
installation.
The appliance must not be installed
behind a lockable door, a sliding
door or a door with a hinge on the
opposite side to that of the tumble
dryer, in such a way that a full
opening of the tumble dryer door is
restricted.
Transporting the machine to its
installation site
When moving the machine, you can
hold it by the lid where it protrudes to
the rear of the dryer. To manoeuvre the
dryer out of its packing case to its
installation site you will also need to
hold it by the front feet.
