Miele WDB 030 User Manual

Technical data
68
Height 850 mm
Width 596 mm
Depth 636 mm
Depth with door open 1054 mm
Height for building under 850 mm
Width for building under 600 mm
Weight Approx. 100 kg
Capacity 7 kg dry laundry
Voltage See data plate
Connected load See data plate
Fuse rating See data plate
Consumption data See "Consumption data"
Minimum flow pressure 100 kPa
Maximum flow pressure 1000 kPa
Inlet hose length 1.60 m
Drain hose length 1.50 m
Mains connection cable length 2.00 m
Delivery head max. 1.00 m
Maximum drainage length 5.00 m
LEDs Class 1
Test certificates awarded See data plate
Power consumption when switched off 0.3 W
Power consumption when not switched off 2.5 W

Miele WDB 030 Specifications

General

Brand	Miele
Model	WDB 030
Category	Washer
Language	English
