Programming Interface
• All codes are four (4) digits in length.
• Entry code is a four (4) digit code needed to activate the gate.
• Master Code is needed to add, remove or reset entry codes.
• Master Code also functions as the entry code under normal operation.
• Factory default Master Code is 1234.
• STATUS light should blink and beeper should beep (once) whenever
any button is pressed.
• If more than 10 seconds elapsed between key presses the unit returns
to normal (idle) operating mode.
• Keypad can only enter program mode from sleep mode (keypad is
turned OFF).
• Keypad will beep three times before going into sleep mode.
Program New Master Code
• Press and release PROGRAM button.
• Enter the old Master Code then press and release PROGRAM button.
• Enter 0, 6 then press and release PROGRAM button
• Enter the new Master Code then press and release PROGRAM button.
• Enter the new Master Code then press and release PROGRAM button
again for conrmation.
• Beeper beeps 3 times to conrm that the new Master Code is
accepted.
NOTE: If the Master Code is not a matched pair or error occurs, (i.e. if
the entry code is NOT a 4-digit code) the STATUS light will ash rapidly
and the beeper will sound for 2 seconds before returning to normal
operation with old Master Code.
Example: Key press sequence to change old Master Code from 1 2 3 4
to 3 1 2 1
1 2 3 4 0 6 3 1 2 1 3 1 2 1
The round black dot is the ‘PROGRAM’ button.
Program (Add) New Entry Code
• Press and release PROGRAM button.
• Enter the Master Code then press and release PROGRAM button.
• Enter 0, 2 then press and release PROGRAM button.
NOTE: If memory is full (all 25 locations are already programmed) the
STATUS light will ash rapidly and the beeper will sound for 2 seconds
before returning to normal operation without saving.
• Enter the new Entry Code then press and release PROGRAM button.
• Beeper beeps 3 times to conrm that the new Entry Code is
accepted.
NOTE: If the code is NOT 4-digits in length or an error condition has
occurred. The STATUS light will ash rapidly and the beeper will sound
for 2 seconds before returning to normal operation without saving.
Example: Key press sequence to add ‘3456’ as a new entry code.
(1234 is the Master Code)
The round black dot is the ‘PROGRAM’ button.
Program (Add) New Temporary
Entry Code
• Press and release PROGRAM button.
• Enter the Master Code then press and release PROGRAM button.
• Enter 8, and any number between 1 thru 7 then press and release
the PROGRAM button. The number 1 thru 7 indicates the number
of days after which the code will be automatically removed from
memory
NOTE: If memory is full (all 25 locations are already programmed)
or an invalid entry is detected, then an error condition has occurred.
The STATUS light will ash rapidly and the beeper will sound for 2
seconds before returning to normal operation without saving.
• Enter the new Entry Code then press and release PROGRAM
button.
• Beeper beeps 3 times to conrm that the new Entry Code is
accepted.
NOTE: If the code is NOT 4-digits in length or an error condition
has occurred, the STATUS light will ash rapidly and the beeper will
sound for 2 seconds before returning to normal operation without
saving.
Example: Key press sequence to add “3456” as a new entry code
that will remain valid for 2-days only. (1234 is the Master Code)
The round black dot is the ‘PROGRAM’ button.
Example: Key press sequence to add “3456” as a new entry code
that will remain valid for 7-days only. (1234 is the Master Code)
The round black dot is the ‘PROGRAM’ button.
Programming the Keypad
Delete An Entry Code
• Press and release PROGRAM button.
• Enter the Master Code then press and release PROGRAM button.
• Enter 0, 3 then press and release PROGRAM button.
• Enter the Entry Code to be deleted then press and release
PROGRAM button.
• Beeper beeps 3 times to conrm that the new Entry Code is
deleted.
NOTE: If no matching code is found or the code is NOT 4-digit in
length, then an error condition has occurred. The STATUS light will
ash rapidly and the beeper will sound for 2 seconds before returning
to normal operation without saving.
Example: Key press sequence to delete entry code ‘3456’ from
memory. (1234 is the Master Code)
The round black dot is the ‘PROGRAM’ button.
1 2 3 4 0 2 3 4 5 6
1 2 3 4 8 2 3 4 5 6
1 2 3 4 0 3 3 4 5 6
1 2 3 4 8 7 3 4 5 6
