MM362 Installation Instructions 1
MIGHTY MULE MM362 DUAL GATE OPENER
_____________________________________
DRIVE
_____________________________________
• Low friction screw drive (linear actuator) rated for -5 °F to +160 °F (-20 °C to +71 °C).
• Powered by a 12 V motor with integral case hardened steel gear reducer. Motor speed reduced to 260 rpm.
Generates 520 inch lb. of torque at 12 V.
• Maximum opening arc of 110°. Approximate opening time (90°): 18 seconds, depending on weight of gate.
_____________________________________
POWER
_____________________________________
• The system is powered by a 12 Vdc automotive or lawn tractor battery.
• Battery charge is maintained by a 120 Vac, 14 Vac output transformer (10 VA) through the GTO control board] or
by optional GTO Solar Panels; the panel should generate minimum of 10 Watts (600 mA). A diode on the control
board prevents battery discharge. IMPORTANT: Never use both transformer and solar panel— this will damage
the battery and control board.
• One (1) blade-style fuse is rated for 25 A.
NOTE: The transformer should not be directly connected to any battery. Do not replace fuses with
higher ampere rated fuses; doing so will void your warranty and may damage your control board.
_____________________________________
CONTROL
_____________________________________
• GTO microprocessor-based control board is set for dual leaf, pull-to-open gate installations. Jumper can be
removed to accommodate an optional kit for push-to-open gates.
• Control board has temperature compensated circuits.
• A circuit on the control board regulates charging. “Sleep draw” is 15 mA; “active draw” is 2 to 5 A.
• Auto-memorization of digital transmitter code.
• GTO RF receiver tuned to 318 MHz.
• Opener length with push-pull tube fully retracted is 26
3
/8", mounting point to mounting point. Maximum stroke is
13".
• Adjustable auto-close timer (OFF to 3–120 seconds), and Dual Sense Technology™ stall force).
• Power terminal block accommodates a transformer or solar panels.
• Accessory terminal block fully compatible with all Mighty Mule access controls.
• Control board allows connection of edge sensors and photoelectric sensors.
• Audio entrapment alarm sounds if unit encounters an obstruction twice while opening or closing.
_____________________________________
OPERATIONAL CAPACITY
_____________________________________
• The Gate Capacity Chart shows approximate cycles, per day, you could achieve prior to the 12 Volt battery
depleting to a state where the unit will not function. This chart reflects a Mighty Mule Automatic Gate Opener
when charging with a transformer and 12 Volt battery. Actual cycles may vary slightly depending upon the type
and condition of gate and installation.
NOTE: BALL BEARING HINGES SHOULD BE USED ON ALL GATES WEIGHING OVER 250 LB.
To determine the number of cycles the gate opener will perform using solar panels, please see the specifications
or call (800) 543-1236 or (850) 575-4144 for more information.
Gate Weight
Gate Length
Number of Cycles Per Day
Mighty Mule 362 Gate Capacity/Cycle Chart
Estimated number of daily cycles, based on use with a transformer.
300 lbs.
150 lbs.
100 lbs.
50 lbs.
39
41
44
46
5' - 6'
36
39
41
44
8'
34
36
39
42
10'
31
34
36
39
12'
An operation cycle is
one full opening and
closing of the gate.
These specifications
are subject to change
with out notice.
