MM362 Installation Instructions 25
VOLTAGE RATINGS
14 Vac Transformer _____________ 13.0 to 16.0 Vac
10 W Solar panel _______________ 18.0 to 22.0 Vdc 600 mA
Measure voltage at panel and control box.
12 V Battery ____________________ 12.5 to 13.5 Vdc
Charging circuit ________________ 13.8 to 14.8 Vdc
Measure voltage at battery terminals with battery connected
