MikroTik cAP XL ac Manual

1.
2.
3.
4.
5.
6.
Scan QR code and choose your preferred OS.
Install and open application.
By default, the IP address and user name will be already entered.
Click Connect to establish a connection to your device through a wireless network.
Choose Quick setup and application will guide you through all basic configuration settings in a couple of easy steps.
An advanced menu is available to fully configure all necessary settings.
Notice
The Frequency band 5.470-5.725 GHz isn’t allowed for commercial use.
In case WLAN devices work with different ranges than the above regulations, then a customized firmware version from the manufacturer/supplier
is required to be applied to the end-user equipment and also prevent the end-user from reconfiguration.
For Outdoor Usage: End-user requires approval/license from the NTRA.
Datasheet for any device is available on the official manufacturer website.
Products with the letters “EG” at the end of their serial number have their wireless frequency range limited to 2.400 – 2.4835 GHz, the TX power is
limited to 20dBm (EIRP).
Products with the letters “EG” at the end of their serial number have their wireless frequency range limited to 5.150 – 5.250 GHz, the TX power is
limited to 23dBm (EIRP).
Products with the letters “EG” at the end of their serial number have their wireless frequency range limited to 5.250 – 5.350 GHz, the TX power is
limited to 20dBm (EIRP).
Federal Communication Commission Interference Statement
Model FCC ID
-US RBcAPGi-5acD2nD-XL TV7CPGI52XL
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment
does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate this
equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Note: This unit was tested with shielded cables on the peripheral devices. Shielded cables must be used with the unit to ensure compliance.
Please make sure the device has a locking package (firmware version from the manufacturer) which is required to be applied to the end-user
equipment to prevent the end-user from reconfiguration. The product will be marked with country code “-EG”. This device needs to be upgraded
to the latest version to ensure compliance with local authority regulations! It is the end users' responsibility to follow local country regulations,
including operation within legal frequency channels, output power, cabling requirements, and Dynamic Frequency Selection (DFS)
requirements. All MikroTik radio devices must be professionally installed.

MikroTik cAP XL ac Specifications

General

2.4 GHz	Yes
Frequency band	2 - 5.5 GHz
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.3af, IEEE 802.3at
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Transmitting power (CE)	26 dBm
Maximum data transfer rate	867 Mbit/s
Mean time between failures (MTBF)	100000 h
Maximum data transfer rate (2.4 GHz)	300 Mbit/s
Security features	IPsec hardware acceleration
Security algorithms	-
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	2
Input current	1.2 A
AC input voltage	17 - 57 V
DC voltage range	24 V
Power consumption (max)	24 W
Power consumption (typical)	11 W
Power over Ethernet (PoE) type supported	Passive PoE
Placement	Ceiling, Wall
Product color	White
Antenna type	Internal
Chipset	IPQ-4018
Flash memory	128 MB
Internal memory	16 MB
Processor model	IPQ4018
Processor frequency	716 MHz
Operating system installed	RouterOS
Warranty period	5 year(s)
Sustainability certificates	CE, Federal Communications Commission (FCC), RoHS
Wireless technology	Wi-Fi 5

Weight and Dimensions

Width	191 mm
Height	42 mm
