MikroTik cAP XL ac User Manual

Hereby, Mikrotīkls SIA declares that the radio equipment type RBcAPGi-5acD2nD-XL is in compliance with Directive 2014/53/EU. The full text of the EU
declaration of conformity is available at the following internet address:https://mikrotik.com/products
Frequency bands terms of use
Frequency range (for applicable models) Channels used Maximum Output Power (EIRP) Restriction
2412-2472 MHz 1 - 13 20 dBm Without any restriction to use in all EU Member States
5150-5250 MHz 26 - 48 23 dBm Restricted to indoor use only*
5250-5350 MHz 52 - 64 20 dBm Restricted to indoor use only*
5470-5725 MHz 100 - 140 27 dBm Without any restriction to use in all EU Member States
* It is the customer's responsibility to follow local country regulations, including operation within legal frequency channels, output power, cabling
requirements, and Dynamic Frequency Selection (DFS) requirements. All Mikrotik radio devices must be professionally installed!
This MikroTik device meets Maximum WLAN transmit power limits per ETSI regulations. For more detailed information see Declaration of
Conformity above / Dieses MikroTik-Gerät erfüllt die maximalen WLAN Sendeleistung Grenzwerte gemäß ETSI-Bestimmungen. Weitere
Informationen finden Sie oben unter Konformitätserklärung / Cet appareil MikroTik respecte les limites maximales de puissance de transmission
WLAN conformément aux réglementations ETSI. Pour plus d'informations, voir la déclaration de conformité ci-dessus / Questo dispositivo
MikroTik è conforme ai limiti massimi di potenza di trasmissione WLAN in conformità con le normative ETSI. Per ulteriori informazioni,
consultare la dichiarazione di conformità sopra / Este dispositivo MikroTik cumple con los límites máximos de potencia de transmisión WLAN de
acuerdo con las regulaciones ETSI. Para obtener más información, consulte la declaración de conformidad anterior / Это устройство MikroTik
соответствует максимальным пределам мощности передачи WLAN в соответствии с правилами ETSI. Для получения дополнительной
информации см. Декларацию соответствия выше.
The WLAN function for this device is restricted to indoor use only when operating in the 5150 to 5350 MHz frequency
range. / Die WLAN-Funktion dieses Geräts ist nur für die Verwendung in Innenräumen im Frequenzbereich 5150 bis 5350
MHz beschränkt. / La fonction WLAN de cet appareil est limitée à une utilisation en intérieur uniquement lorsqu'il fonctionne
dans la gamme de fréquences 5150 à 5350 MHz. / La funzione WLAN per questo dispositivo è limitata all'uso interno solo
quando si opera nella gamma di frequenza da 5150 a 5350 MHz. / La función WLAN para este dispositivo está restringida
al uso en interiores solo cuando se opera en el rango de frecuencia de 5150 a 5350 MHz. / Функция WLAN для этого
устройства ограничена использованием внутри помещения только при работе в диапазоне частот от 5150 до 5350 МГц.
Note. The information contained here is subject to change. Please visit the product page on  www.mikrotik.com  for the most up to date version of
this document.

MikroTik cAP XL ac Specifications

General

2.4 GHz	Yes
Frequency band	2 - 5.5 GHz
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.3af, IEEE 802.3at
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Transmitting power (CE)	26 dBm
Maximum data transfer rate	867 Mbit/s
Mean time between failures (MTBF)	100000 h
Maximum data transfer rate (2.4 GHz)	300 Mbit/s
Security features	IPsec hardware acceleration
Security algorithms	-
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	2
Input current	1.2 A
AC input voltage	17 - 57 V
DC voltage range	24 V
Power consumption (max)	24 W
Power consumption (typical)	11 W
Power over Ethernet (PoE) type supported	Passive PoE
Placement	Ceiling, Wall
Product color	White
Antenna type	Internal
Chipset	IPQ-4018
Flash memory	128 MB
Internal memory	16 MB
Processor model	IPQ4018
Processor frequency	716 MHz
Operating system installed	RouterOS
Warranty period	5 year(s)
Sustainability certificates	CE, Federal Communications Commission (FCC), RoHS
Wireless technology	Wi-Fi 5

Weight and Dimensions

Width	191 mm
Height	42 mm
