MikroTik MANTBox 52 15s User Manual

1. Attach the quick mount to the back of the device.
2. Attach the device to the pole and secure it with a provided steel clamp. Clamping diameter 35 – 70
mm.
3. Please avoid connecting a loose Ethernet cable to the Ethernet port, secure the cable to a wall or the
pole, so that the cable weight is not pulling the port. It is recommended to secure the Ethernet cable less
than 2m from the device. This is to ensure that the cable doesn't damage the port by its weight, or
doesn't fall out.
We recommend using Cat6 shielded cables.
Warning! This equipment should be installed and operated with a minimum distance of 25 cm between
the device and your body. The operation of this equipment in the residential environment could cause
radio interference.
Configuration
We recommend clicking the "Check for updates" button and updating your RouterOS software to the
latest version to ensure the best performance and stability. RouterOS includes many configuration
options in addition to what is described in this document. We suggest visiting the RouterOS
documentation page to get yourself accustomed to the possibilities: https://mt.lv/help.
In case an IP connection is not available, the Winbox tool (https://mt.lv/winbox) can be used to connect
to the MAC address of the device from the LAN side (all access is blocked from the internet port by
default).
First-time configuration https://mt.lv/configuration;

MikroTik MANTBox 52 15s Specifications

General

Frequency band	2.4/5 GHz
Networking standards	IEEE 802.11b, IEEE 802.11g
Antenna gain level (max)	15 dBi
Mounting	Pole
Antenna type	Sector antenna
Polarization	Dual polarization
Antenna connector type	-
Power consumption (max)	21 W
Operating temperature (T-T)	-30 - 70 °C
Quantity per pack	1 pc(s)
Harmonized System (HS) code	85177100

Weight and Dimensions

Depth	140 mm
Width	348 mm
Height	82 mm
