MikroTik Wireless Wire Cube User Manual

Alternatively, the device can be mounted on one of the three mounting slots on the backside of the device.
You can use a metal ring for example.
Use a Phillips screwdriver to loosen the metal ring.
Slide one end of it through the most convenient of the three mounting slots.
Position the device on the pole where it will be mounted.
Slide the loose end of the mounting ring back to its closing latch and use the screwdriver to tighten it.
The IP rating scale for this device is IP54. When mounting outdoors, please ensure that any cable openings are directed downwards. We
recommend using the POE injector and proper grounding with Cat6 shielded cable. When using and installing this device please pay attention
to Maximum Permissible Exposure (MPE) safety distance with a minimum of 20 cm between the radiator and your body.

MikroTik Wireless Wire Cube Specifications

General

Flash memory	16 MB
Internal memory	256 MB
Processor model	IPQ4019
Built-in processor	Yes
Processor frequency	716 MHz
Processor manufacturer	Qualcomm
Operating system installed	RouterOS
2.4 GHz	No
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11n, IEEE 802.3af, IEEE 802.3at
Receiver sensitivity	-93 (6MBit/s), -74 (54MBit/s), -93 (MCS0), -71 (MCS7), -68 (MCS9)
Maximum outdoor range	800 m
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mean time between failures (MTBF)	200000 h
Maximum data transfer rate (5 GHz)	433 Mbit/s
Operating temperature (T-T)	-40 - 70 °C
Placement	Pole, Wall
Certification	CE, FCC, IC, EAC, RoHS
Product color	White
Output current	0.8 A
Output voltage	24 V
AC input voltage	12 - 57 V
Power consumption (max)	9 W
Antenna type	Internal
Antenna gain level (max)	11.5 dBi
Number of products included	1 pc(s)
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Security algorithms	-

Weight and Dimensions

Width	130 mm
Height	132 mm
