iMap10.0
2.2 Robot and dust box
- 06 -
Wi-Fi indicator:
Blinking slowly in white: Wait for connection
Blinking fast in white: Being connected to Wi-Fi
Normally on in white: Wi-Fi connected
System reset button
Water outlet adapter
Dust box and water tank
Button for taking out dust box and water tank
Combination of water tank
and dust box (detachable)
Air outlet
Water tank outlet
Water inlet cap
Filter
Cleaning brush
Water inlet
Buckle
Pre-filter
Foam filter
Dust box and water
tank separation button
High-performance filter
Suction inlet
