WINCH FEATURES & SPECS
SPECIFICATIONS (15K):
Rated Line Pull 15000 lbs (6803 kgs)
Gear Train 3 Stage planetary
Gear Ratio 294:1
Motor
Series wound, 6.8 hp (5 kw), 12 Volt
24 Volt available
Remote
Power in, Power out with 12’ cable
(3.7 m)
Dimensions
(LxWxH)
22” X 6.3” X 8.3”
(558 mm X 160 mm X 211 mm)
Steel Cable
025/64” X 72’ (010 mm X 22 m)
(16,409 lb. breaking strength)
Synthetic Rope
3/8” X 78’ (9.5 mm X 23.7 m)
(18,078 lb. breaking strength)
Drum Size
Diameter x Length
2.9” X 8.9” (75 mm X 226 mm )
Net Weight
Synthetic Rope
63 lbs (28.5 kgs)
Net Weight
Steel Cable
85 lbs (38.5 kgs)
Bolt Pattern
4 bolt pattern, 4.5” x 10”
(114.3 mm X 254 mm)
PERFORMANCE (15K):
Line Pull Line Speed Motor Current
lb kg fpm mpm amps @ 12 V
0 0 16.7 5 120
4000 1816 12 3.7 202
6000 2724 10.5 3.2 225
8000 3632 9.2 2.8 250
10000 4540 7.9 2.4 310
12000 5448 6.6 2 355
15000 6810 5.9 1.8 420
FEATURES:
•6.8 HP Series Wound Motor
•Rugged Planetary Gear Sets
•Clockable Gear Housing
•Fast Line Speeds
•Submersible, 400 Amp Solenoid
•Automatic Load Holding Brake
•Corrosion Resistant Stainless Steel Fasteners
•79’ Steel Cable or 78’ Synthetic Rope
•Aluminum Hawse or Roller Fairlead
•Waterproof
•Handheld Remote Control
•Includes 15’ Recovery Strap
SEC15
*Steel Cable 76-50260W
Synthetic Rope 76-53260W
2121 Blount Road Pompano Beach, FL 33069 MileMarker.com 1.800.886.8647 PAGE 12
* PICTURED
