WINCH FEATURES & SPECS
*Steel Cable 76-50251BW
PERFORMANCE (12K):
Line Pull Line Speed Motor Current
lb kg fpm mpm amps @ 12 V
0 0 16.4 5 85
4000 1816 8.8 2.7 160
6000 2724 7.5 2.3 191
8000 3632 6.7 2 235
10000 4540 5.6 1.7 270
12000 5448 4.9 1.5 320
PERFORMANCE (9.5K):
Line Pull Line Speed Motor Current
lb kg fpm mpm amps @ 12 V
0 0 21 6.4 86
2000 908 11 3.4 150
4000 1816 8.8 2.7 205
6000 2724 7.5 2.3 235
8000 3632 6 1.8 252
9500 4313 4.3 1.3 330
SPECIFICATIONS (12K):
Rated Line Pull 12000 lbs (5443 kg)
Gear Train 3 Stage planetary
Gear Ratio 294:1
Motor
Series wound, 4.9 hp (3.6 kw),
12 Volt, 24 Volt available
Remote
Power in, Power out with 12’
cable (3.7 m)
Dimensions (LxWxH)
20.8” X 6.34” X 7.86”
(528 mm X 161 mm X 200 mm)
Steel Cable
3/8” X 100’ (9.5 mm X 30.5 m)
(14,400 lb. breaking strength)
Synthetic Rope
3/8” X 92’ (9.5 mm X 28 m)
(18,078 lb. breaking strength)
Drum Size
Diameter X Length
2.6” X 8.35” (67 mm X 212 mm)
Net Weight
Synthetic Rope
48 lbs (30.39 kg)
Net Weight
Steel Cable
67 lbs (41.73 kg)
Bolt Pattern
4 Bolt pattern, 4.5” x 10”
(114.3 mm X 254 mm)
FEATURES:
•4.9 HP Series Wound Motor
•Rugged Planetary Gear Sets
•Clockable Gear Housing
•Fast Line Speeds
•Submersible, 400 Amp Solenoid
•Automatic Load Holding Brake
•Corrosion Resistant Stainless
Steel Fasteners
100’ Steel Cable or 92’ Synthetic Rope
Aluminum Hawse or Roller Fairlead
• Waterproof
•Handheld Remote Control
SPECIFICATIONS (9.5K):
Rated Line Pull 9500 lbs (4309 kg)
Gear Train 3 Stage planetary
Gear Ratio 210:1
Motor
Series wound, 4.9 hp (3.6 kw),
12 Volt, 24 Volt available
Remote
Power in, Power out with 12’
cable (3.7 m)
Dimensions (LxWxH)
20.8” X 6.34” X 7.86”
(528 mm X 161 mm X 200 mm)
Steel Cable
3/8” X 100’ (9.53 mm X 30.5 m)
(14,400 lb. breaking strength)
Synthetic Rope
3/8” X 92’ (9.5 mm X 28 m)
(18,078 lb. breaking strength)
Drum Size
Diameter X Length
2.64” X 8.7” (67 mm X 222mm )
Net Weight
Synthetic Rope
48 lbs (30.39 kg)
Net Weight
Steel Cable
67 lbs (41.73 kg)
Bolt Pattern
4 Bolt pattern, 4.5” x 10”
(114.3 mm X 254 mm)
Synthetic Rope 76-53251BW
*Steel Cable
Synthetic Rope
76-50246BW
76-53246BW
2121 Blount Road Pompano Beach, FL 33069 MileMarker.com 1.800.886.8647PAGE 13
* PICTURED
