WINCH FEATURES & SPECS
SPECIFICATIONS (8K):
Rated Line Pull 8000 lbs (3629 kg)
Gear Train 3 Stage planetary
Gear Ratio 150:1
Motor
Series wound, 4.9 hp (3.6 kw), 12 V
24 Volt available
Remote Power in, Power out with 12’ cable (3.7 m)
Dimensions (LxWxH)
20.8” X 6.34” X 7.86”
(528 mm X 161 mm X 200 mm)
Steel Cable
5/16” X 92’ (7.94 mm X 28 m)
(9,800 lb. breaking strength)
Synthetic Rope
5/16” X 92’ (7.94 mm X 28 m)
(13,228lb. breaking strength)
Drum Size
Diameter X length
2.5” X 8.3” (63 mm X 222 mm)
Net Weight
Synthetic Rope
49 lbs (37 kg)
Net Weight
Steel Cable
63 lbs (31.75 kg)
Bolt Pattern
4 bolt pattern, 4.5” x 10”
(114.3 mm X 254 mm)
PERFORMANCE: (8K)
Line Pull Line Speed Motor Current
lb kg fpm mpm amps @ 12 V
0 0 38.1 11.6 70
2000 908 14.1 4.3 136
4000 1816 12.5 3.8 198
6000 2724 9.8 3 264
8000 3632 8.2 2.5 284
FEATURES:
•4.9 HP Series Wound Motor
•Rugged Planetary Gear Sets
•Clockable Gear Housing
•Fast Line Speeds
•Submersible, 400 Amp Solenoid
•Automatic Load Holding Brake
•Corrosion Resistant Stainless Steel Fasteners
• 100’ Steel Cable or 92’ Synthetic Rope
• Aluminum Hawse or Roller Fairlead
• Waterproof
• Handheld Remote Control
*Steel Cable 77-50141W
Synthetic Rope 77-53141W
2121 Blount Road Pompano Beach, FL 33069 MileMarker.com 1.800.886.8647 PAGE 14
* PICTURED
