4 Installation
Setup, connecting pads and pedals
Setup and assembly of the pads and pedals are described in detail in the enclosed assembly guide. Finally check that all cables
between the pads and the e-drum module have been properly connected.
Connecting the power adapter
Use the Y cable to connect the supplied power adapter to the [9 V] port of the e-drum module and the hi-hat controller. Then
plug the mains plug into the socket.
Connecting headphones
Connect your stereo headphones to the [PHONES] output of the drum module.
Connecting audio devices
Connect the inputs of your amplifier or active monitors to the [OUTPUT] sockets of the drum module. If you use a mono amplifier,
connect its input to the [L/MONO] output socket of the module.
Connecting a CD or MP3 player
Connect a CD or MP3 player to the input socket [AUX IN] IN of the drum module.
Connecting MIDI devices
Connect external MIDI devices to the [MIDI OUT] or [MIDI IN] socket of the drum module.
Connecting USB devices
Connect external MIDI devices or your computer to the USB port [USB MIDI] of the drum module.
Installation
e-drum module
8
