Figure 2: 9700W Front Panel Showing Operator Interface and functions of dials, switches
3 Remote Receptacles
S3 top, S2 middle, S1 at
bottom
120 VAC input
Knob, Dial adjust for screen- CW
more and CCW less
4 touch arrows/buttons for
screen navigation
4 Line Screen
display
Ground Stud
On/off Circuit
Breaker
Weld start and stop
Mounting holes-4 places
