16
RUN
Run is either Normal or Dry. If Dry, the wire will not feed when the
external signal is send. Also the Run will change to Dry Run in
the run screens. If Normal, the system will run normally on the
external start.
3. AUX1-3 SCREENS
To get out of the AUX1-3 sub menu all you have to do is press the left arrow. Also if you do have an auxiliary
output the name shown will be what is programmed in Configuration Mode / AUX1-3
START DELAY
This is the amount of time from when the 9700W gets a start
command until the output becomes active. Minimum value is 0.0,
Maximum value is 10.0.
STOP DELAY
Stop Dly is the amount of time that the auxiliary output is shorted
after the 9700W gets a stop command. Minimum value is 0.0,
Maximum value is 10.0.
AUX1-3 ENABLE/DISABLE
AUX 1-3 is enable or disable. If enable then the auxiliary output
signal will be activated during the weld. If disable the auxiliary
output will stay open.
4. PULSED SCREENS
To get out of the pulsed sub menu all you have to do is press the left arrow.
