APPENDIX B 9700W CONFIGURATION SUB MENU MODE
You enter the Configuration mode from the program mode. To get out of the configuration sub menu all
you have to do is press the left arrow. When you leave the calibration sub menu all settings will be saved to
the main configuration permanent memory. Default Password is CONFI
FORWARD JOG
Fwd Jog is the percentage of the high speed that is moved when
jogging forward. Minimum value is 5 and Maximum value is 100.
REVERSE JOG
Rev Jog is the percentage of the high speed that is moved when
jogging reverse. Minimum value is 5 and Maximum value is 100.
RAPID JOG
Rapid Jog is the percentage of the high speed that is moved when
doing a rapid jog or wire retract. Minimum value is 5 and
Maximum value is 100.
RAMP ENABLE
Ramp Enable is either yes or no. If yes, then Ramp Time is
displayed in the main screen.
CONFIG
