1. RUN SCREENS
The operator must be in either of these two screens in order to begin a weld. If the right or left buttons are
pressed in the run screens, it will cause the wire to feed. A single press will give jog speed. A double press
will give rapid speed. If the up button is pressed with moving, that speed will be maintained without the
buttons pressed until the stop button is pressed. When in the program portion of the menu, a left arrow
will save all the program parameters to the main menu.
WIRE SPEED
The wire screen sets the travel speed of the torch during the weld.
Wire feed speed is shown in IPM (inches per minute) or CPM
(centimeters per minute).
The number of decimal places is set in Configuration / Set DP.
The unit will limit the programmed speed to be between the high
and low speeds set up in the Calibration.
UNLOCKED OR LOCKED
The unlocked setting allows the user to change the speed during
the weld by adjusting the knob. Locked does not allow the user to
change the speed during the weld.
2. PROGRAM SCREENS
Pressing the left arrow in any of the program screens will save the entire program to the permanent
memory of the 9700W.
WIRE START DLY
If the wire is started by the external contact this is the delay after
getting the signal from when the wire starts to move. If started by
the Start button on the panel this value is dismissed and the wire
starts immediately. Minimum value is 0.0, Maximum value is
10.0.
