12
SECTION III
OPERATION MODE 9700W
This mode is used by the operator to feed weld wire.
To set the conditions for operation, the operator can scroll through the various screens and make
the appropriate changes using the up/down and left/right arrows on the face of the control.
When changing a numeric value each click of the dial will increase or decrease the value by one. If
the up button is pressed then each click of the dial increases or decreases the value by 10. Pressing
the up button again allows the dial to change values by 100 per click. Using the down button will
move the values back to 10 and pressing down again will move the values back to 1. The number
location to be changed will be inversed until the dial is moved. The number 10 will appear on the
top line while the up and down buttons will change the number location.
Operator Mode consists of two main sections- Run, and
Program. Both sections are linked together to form one list.
Some entries in the program section also have sub menus.
The four sub menus are –Aux1, Aux2, Aux3 and Pulsed. Use
the right arrow to enter them and then you navigate as you
would before. Use the left arrow to return to the Operator
mode main section.
Please note that not all the screens in this manual appear on your 9700W. Your system or control
might not have the function. During programming if you disable a function it will not appear in run
screens.
WELCOME SCREEN
This screen appears automatically when the unit is switched on and remains on the screen for
approximately 3 seconds.
The next screen will appear automatically.
