Miller Bobcat 225 NT User Manual

14 OM-405
Continuous Welding
3.6 Duty Cycle
SB-119 454-A
Duty cycle is the percentage of 10
minutes that unit can weld at rated
load without overheating.
 Exceeding duty cycle can
damage unit and void
warranty.
100% Duty Cycle at 225 Amperes CC/AC, 210 Amperes CC/DC, 200 Amperes CV/DC
3.7 Volt-Ampere Curves
ST-166 024-A / ST-166 025-A / ST-166 026-A
The volt-ampere curve shows the
minimum and maximum voltage
and amperage output capabilities of
the welding generator. Curves of all
other settings fall between the
curves shown.
A. For CC/AC Mode
B. For CC/DC Mode
C. For CV/DC Mode

Miller Bobcat 225 NT Specifications

General

Rated Output Power	8, 000 watts
Engine	Kohler CH730
Fuel Type	Gasoline
Fuel Tank Capacity	12 gallons
AC Output	120/240 V
DC Output	12 V
Engine Type	OHV
