Processes
OM-1324 204 408E
January 2004
Arc Welding Power Source And
Wire Feeder
Description
MIG (GMAW) Welding
Flux Cored (FCAW) Welding
Millermatic
135/175
And M-10 Gun

Table of Contents

Questions and Answers

  • K
    Kevin BrownAug 2, 2025
    What to do if electrode wire feeding stops during welding with Miller MILLERMATIC 135 Welding System?
    • T
      trodriguezAug 2, 2025
      If the electrode wire feeding stops during welding with your Miller Welding System, there are several potential solutions: * Ensure the gun cable is straight, and replace any damaged parts. * Adjust the drive roll pressure. * Change to the correct drive roll groove. * Readjust the hub tension. * Replace a blocked contact tip (an oversized tip might be needed for certain wires). * Clean or replace a dirty or plugged wire inlet guide or liner. * Replace worn or slipping drive rolls or pressure bearings. * Secure or repair the gun trigger leads. * Check for and clear any restrictions at the drive assembly and liner. * Release the gun trigger to allow the gun and motor protection circuitry to reset. * Have a Factory Authorized Service Agent inspect the drive motor.
  • G
    gpearsonAug 7, 2025
    Why Miller Welding System has no weld output, wire doesn't feed, but fan motor runs?
    • J
      James MooreAug 7, 2025
      If your Miller Welding System has no weld output, the wire doesn't feed, but the fan motor still runs, it could be due to a couple of reasons. First, the thermostat TP1 might be open due to overheating. To resolve this, let the fan run with the gun trigger switch off until the unit cools down and the thermostat closes. Second, ensure the gun trigger leads are securely connected.
  • E
    Edward WilsonAug 14, 2025
    What to do if Miller MILLERMATIC 135 Welding System has no weld output but the wire feeds?
    • C
      Charles AlexanderAug 14, 2025
      If your Miller Welding System has no weld output and the wire feeds, ensure the work clamp is connected for good metal-to-metal contact. Also, replace the contact tip, check for proper polarity connections, and tighten the thumbscrew securing the gun end to the feed head adapter.
  • K
    Kathryn BeckAug 20, 2025
    How to troubleshoot Miller MILLERMATIC 135 Welding System with no weld output, wire feed, and fan?
    • R
      Rebecca WintersAug 20, 2025
      If your Miller Welding System has no weld output, the wire doesn't feed, and the fan doesn't run, check the following: ensure the power cord is securely plugged into the receptacle, replace the building line fuse or reset the circuit breaker if it's open, make sure the power switch is in the On position, and reset the welding power source circuit breaker if it's open.
  • D
    david85Aug 26, 2025
    Why Miller Welding System has low weld output?
    • T
      Tristan MendozaAug 26, 2025
      If your Miller Welding System has low weld output, connect the unit to the correct input voltage or check for low line voltage. You may also need to place the voltage switch in the appropriate position.

Summary

Safety Precautions and Hazards

Symbol Usage

Explains symbols used in the manual for hazard identification.

Arc Welding Hazards

Details common hazards associated with arc welding processes.

Principal Safety Standards

Lists key safety standards and organizations for welding.

Specifications and Performance

Technical Specifications

Provides detailed technical specifications for the 115 VAC and 230 VAC models.

Duty Cycle and Overheating

Explains duty cycle charts and the consequences of overheating for both models.

Installation Guide

Installing Welding Gun

Step-by-step instructions for installing the welding gun assembly.

Changing Polarity

Illustrates how to change the polarity for different welding processes.

Connecting Input Power For 115 VAC Model

Guidance on connecting power for the 115 VAC model.

Threading Welding Wire

Step-by-step guide on how to thread welding wire through the feeder.

Operation and Settings

Controls Overview

Identifies and explains the function of the main controls on the welding unit.

Weld Parameter Chart For 115 VAC Model

Provides recommended settings for the 115 VAC model.

Weld Parameter Chart For 230 VAC Model

Provides recommended settings for the 230 VAC model.

Maintenance and Troubleshooting

Routine Maintenance Schedule

Outlines routine maintenance tasks to be performed at specified intervals.

Troubleshooting Common Issues

A table listing common problems and their remedies.

Electrical Diagrams

Circuit Diagram For 115 VAC Model

Presents the circuit diagram for the 115 VAC model.

Circuit Diagram For 230 VAC Model

Presents the circuit diagram for the 230 VAC model.

MIG Welding Guidelines

MIG Process Control Settings

Provides general guidelines for MIG process control settings.

Holding and Positioning Welding Gun

Demonstrates proper techniques for holding and positioning the welding gun.

Troubleshooting Excessive Spatter

Identifies causes and corrective actions for excessive spatter.

Troubleshooting Lack Of Penetration

Addresses issues related to lack of weld penetration and its causes.

Parts List and Components

Main Assembly Parts

An exploded view and list of main assembly parts for the unit.

M-10 Gun Components

An illustration and parts list for the M-10 welding gun.

Miller True Blue Warranty Information

Miller MILLERMATIC 135 Specifications

General IconGeneral
Output Amperage Range30 - 135 A
Welding ProcessMIG (GMAW)
Welding Amperage Range30 - 135 A
Duty Cycle20% at 90 A
Input Voltage120V
Max Material Thickness1/4 in
Wire Size Range0.023 - 0.035 in
